11. Viewfinder connector
Note
The viewfinder connection cable supplied with the unit is not connected in a 1-1 or 1-N manner.
No.
Signal
I/O
Specifications
1
GND
—
GND
2
GND
—
GND
3
GND(VF_DET2)
—
Cable connection detection signal 2 (GND)
4
CAP_TP_INT
OUT
Touch panel interrupt signal
5
+5V
OUT
+5V power
6
LVDS DATA 2+
OUT
LVDS data 2 (+) output
7
LVDS DATA2-
OUT
LVDS data 2 (-) output
8
LVDS DATA1+
OUT
LVDS data 1 (+) output
9
LVDS DATA 1-
OUT
LVDS data 1 (-) output
10
GND
—
GND
11
GND
—
GND
12
LVDS CLOCK+
OUT
LVDS clock signal (+) output
13
LVDS CLOCK-
OUT
LVDS clock signal (-) output
14
LVDS DATA 0+
OUT
LVDS data 0 (+) output
15
LVDS DATA 0-
OUT
LVDS data 0 (-) output
16
CAP_TP_XRES
IN/OUT
Reset signal from ASTRA to TP
17
STX
OUT
Data signal from VINE to LCD
18
SCK
OUT
Clock signal from VINE to LCD
19
GND
—
GND
20
GND
—
GND
21
I2C SDA
I2C data signal from ASTRA to TP
22
LVDS DATA 3+
OUT
LVDS 3 (+) output
23
LVDS DATA 3-
OUT
LVDS 3 (-) output
24
+5V
OUT
+5Vpower
25
+5V
OUT
+5Vpower
26
XLCD_TXEN(GND)
—
Connect to GND
27
GND
—
GND
28
KEY0_AD2
IN
Key switch AD ladder signal
29
GND
—
GND
30
KEY0_AD3
IN
Key switch AD ladder signal (not used)
31
GND
—
GND
32
TP_SDA
IN/OUT
Data signal from ASTRA to TP
33
GND
—
GND
34
TP_SCL
OUT
Clock signal from Astra to TP
35
GND
—
GND
Continued
1 20
21 40
-External View-
