SON PXW-FX9V - Functions of Onboard LED Indicators

20
No.
Signal
I/O
Specifications
27
HIF_AD5
IN/OUT
28
MONI_3_TX0_N
OUT
29
HIF_AD4
IN/OUT
30
MONI_3_TX0_P
OUT
31
HIF_AD3
IN/OUT
32
GND
—
GND
33
HIF_AD2
IN/OUT
34
MONI_3_TX1_N
OUT
35
HIF_AD1
IN/OUT
36
MONI_3_TX1_P
OUT
37
HIF_AD0
IN/OUT
38
GND
—
GND
39
INT2
IN
40
— —
NC
41
INT1
IN
42
— —
NC
43
GND
—
GND
44
GND
—
GND
45
ETHER_MDI0_P
IN/OUT
46
— —
NC
47
ETHER_MDI0_N
IN/OUT
48
— — —
49
GND
—
GND
50
GND
—
GND
51
GND
—
GND
52
GND
—
GND
53
ETHER_MDI1_P
IN/OUT
54
— —
NC
55
ETHER_MDI1_N
IN/OUT
56
— —
NC
57
GND
—
GND
58
GND
—
GND
59
ETHER_MDI2_P
IN/OUT
60
— —
NC
61
ETHER_MDI2_N
IN/OUT
62
— —
NC
63
GND
—
GND
64
GND
—
GND
65
ETHER_MDI3_P
IN/OUT
66
— —
NC
67
ETHER_MDI3_N
IN/OUT
68
H_DTAPDC_OUT_FET_ON
OUT
69
GND
—
GND
Continued
