SON PXW-FX9V - Page 24

21
No.
Signal
I/O
Specifications
70
GND
—
GND
71
SYS_RST
OUT
72
DTAP_ON
OUT
73
— —
NC
74
H_UR_OCP
IN
75
REF_HD
OUT
76
GND
—
GND
77
REF_24
OUT
78
H_UR_LVP
IN
79
— —
NC
80
BOB_SAG_DET
IN
81
REF_148Mz_P
OUT
82
GND
—
GND
83
REF_148Mz_N
OUT
84
— —
NC
85
— —
NC
86
HD_SYNC0
OUT
87
— —
NC
88
GND
—
GND
89
— —
NC
90
HD_SYNC1
OUT
91
-
—
NC
92
-
—
NC
93
GND
—
GND
94
GND
—
GND
95
GND
—
GND
96
GND
—
GND
97
— —
NC
98
— —
NC
99
USB_CN2_VBUS_EN
OUT
100
USB_CN1_VBUS_EN
OUT
101
GND
—
GND
102
GND
—
GND
103
USB2_PM
IN/OUT
104
— —
NC
105
USB2_DP
IN/OUT
106
— —
NC
107
GND
—
GND
108
GND
—
GND
109
VFSYNC_A
OUT
110
VFSYNC_C
OUT
111
USB_CN2_OC_DET
IN
112
USB_CN1_OC_DET
IN
Continued
