SON PXW-FX9V - Notes on Replacing Parts and Printed Wiring Board

22
No.
Signal
I/O
Specifications
113
RESERVE_1
—
NC
114
GND
—
GND
115
USB1_PM
IN/OUT
116
— —
NC
117
USB1_DP
IN/OUT
118
— —
NC
119
REC_TALLY
OUT
120
GND
—
GND
121
REC_TRIGER
IN
122
— —
NC
123
ADAPTOR_ID[3]
IN
NC
124
— —
NC
125
ADAPTOR_ID[2]
IN
NC
126
GND
—
GND
127
ADAPTOR_ID[1]
IN
128
MCK
OUT
129
ADAPTOR_ID[0]
IN
130
GND
—
GND
131
BOB_3.3V_DET
IN
132
BCK
OUT
133
BATT_ID
IN
134
LRCK
OUT
135
BATT_SCL
IN/OUT
136
GND
—
GND
137
BATT_SDA
IN/OUT
138
ADC_RST_X
OUT
139
POWER_ON
OUT
140
I2S
IN
141
POWER_GOOD
OUT
142
GND
—
GND
143
BODY_DETECT
IN
GND
144
ADAPTOR_DET1_X
IN
145
BOB_BATT_IN
IN
11V to 17V
146
BOB_BATT_IN
IN
11V to 17V
147
BOB_BATT_IN
IN
11V to 17V
148
BOB_DC_IN
IN
11V to 17V
149
BOB_DC_IN
IN
11V to 17V
150
BOB_DC_IN
IN
11V to 17V
151
GND
—
GND
152
GND
—
GND
