SON PXW-FX9V - Media Assembly

65
8. Remove the three radiation sheets E11 T1 (25 x 25) and the two VC radiation sheets (M (913)).
9. Install the removed parts by reversing the steps of removal.
DPR-394 board
Radiation sheets E11 T1 (25 x 25)
VC radiation sheets (M (913))
