Chapter 5: DICOM Connectivity 123
DICOM
To select a location, archiver, printer, or worklist server:
Note: The system must be configured before using DICOM. See “DICOM Configuration” on page 106.
1 Press the Setup key and select Connectivity and then DICOM Setup.
2 In the Location list, select the current location of the TITAN system.
3 In the Device list, select one or more archivers, printers, or worklist servers.
A check mark is displayed next to each device selected. A maximum of two printers, four
archivers, and one worklist server may be selected for each location.
Select the device again to deselect.
4 Complete all configuration information and then select Done from the on-screen menu.
A dialog box is displayed to restart the system.
To verify status of an archiver, printer, or worklist server:
1 Press the Setup key and select Connectivity and then DICOM Setup.
2 From the Device list, select the desired device or devices.
3 Select Done from the on-screen menu.
A dialog box is displayed to restart the system.
The system restarts.
4 Press the Setup key and select Connectivity and then DICOM Setup.
5 Select Verify to confirm that a printer, archiver or worklist server is connected.
AE Title Refers to the Application Entity, the name by which the DICOM devices
on the LAN knows the TITAN system.
Type Type of device: archiver, printer, or worklist server.
Device Name by which TITAN knows the printer, archiver, or worklist server.
Status Indication of whether the device is available for use.
Verify Test to ensure that the selected devices can communicate to the
devices and servers.
Log Log file for troubleshooting DICOM problems. (See “Reviewing the
Network Log” on page 121.)
Config Access to a series of pages for configuring network devices. (See
“DICOM Configuration” on page 106.)
Done Returns to the previous page if no changes are made or restarts the
system if changes are made.
