46 Chapter 3: Imaging
Imaging
Invasive Use
Figure 2 Install Transducer Sheath
Install Transducer
Sheath
Note: SonoSite recommends the use of market-cleared, transducer sheaths for
clinical applications of an invasive nature (such as transvaginal).
1 Place gel inside the sheath.
2 Insert the transducer into the sheath.
Note: To lessen the risk of contamination, install the sheath only when you
are ready to perform the procedure.
3 Pull the sheath over the transducer and cable until the sheath is fully
extended.
4 Secure the sheath using the bands supplied with the sheath.
5 Check for and eliminate bubbles between the footprint of the
transducer and the sheath.
Note: If any bubbles are present between the footprint of the transducer and
the sheath, the ultrasound image may be affected.
6 Inspect the sheath to ensure there are no holes or tears.
