60 Chapter 3: Imaging
Imaging
Image Storage
Save to CompactFlash
Images are saved to the CompactFlash card. The images in the patient list are organized
alphabetically by the patient name and ID. If a name is not entered in the patient name field, a
patient exam is created and identified as (_No_Name_). If an ID number is not entered in the ID
field, the ID number is identified as (_No_ID_).
To review saved images, see “Image Review” on page 61. The images saved on the CompactFlash
card cannot be opened and viewed on a PC. Images may be archived from the ultrasound system
using DICOM Image Transfer or to a PC using SiteLink Image Manager 2.2. See “DICOM
Connectivity” on page 105 or the SiteLink User Guide.
The number of images saved to the CompactFlash card varies depending on the storage capacity of
the card.
Print to Local Printer
Ensure the printer is properly set up for operation with the system. See “Printer” on page 29 for
system setting and the TITAN Accessory User Guide for hardware setup.
Warning: To prevent loss of data, loss of images, or damage to the CompactFlash card, turn
the ultrasound system off before removing the CompactFlash card. When the
CompactFlash card is removed before turning off the ultrasound system, the
system must be restarted.
Save Image
1 Verify the CompactFlash card is inserted into the front slot on the
ultrasound system. See Figure 1 on page 3.
2 Turn system on.
The CompactFlash card is ready to use when the save icon and the
image memory counter, showing the remaining available memory,
are displayed on the screen.
Note: It may take a few seconds for the image memory counter to display
the available memory.
Note: If the CompactFlash card is inserted into the back slot, the save icon
and number are not displayed.
3 Press the Save key to save an image to the CompactFlash card.
After the audible beep is heard, the next image may be saved. It may
take a few seconds for the image memory counter to display the
available memory.
The image memory indicator decreases by one.
Note: Ensure that there is sufficient memory available on the
CompactFlash card before saving additional images.
Print Image
Press the Print key.
