Chapter 9: Specifications 203
Specifications
Chapter 9: Specifications
This chapter contains system and accessory specifications and agency approvals. The specifications
for recommended peripherals can be found in the manufacturers’ instructions.
System Dimensions
Length: 11.8 in. (29.97 cm)
Width: 10.9 in. (27.69 cm)
Depth: 3.0 in. (7.62 cm)
Weight: 8.3 lbs. (3.76 kg) with the C60 transducer and battery installed
Display Dimensions
Length: 5.1875 in. (13.18 cm)
Width: 6.75 in. (17.15 cm)
Diagonal: 8.5 in. (21.59 cm)
Transducers
• C8/8-5 MHz 8 mm curved array (5 ft./1.5 m)
• C11/8-5 MHz 11 mm microcurved array (5 ft./1.5 m)
• C15/4-2 MHz 15 mm microcurved array (5.5 ft./1.7 m)
• C60/5-2 MHz 60 mm curved array (5 ft./1.5 m)
• HST/10-5 MHz 25 mm linear array (8 ft./2.1 m)
• ICT/8-5 MHz 11 mm intracavitary array (5 ft./1.5 m)
• L25/10-5 MHz 25mm linear array (5.5 ft./1.7 m)
• L38/10-5 MHz 38 mm linear array (5.5 ft./1.7 m)
Imaging Modes
2D (256 gray shades)
Color power Doppler (CPD) (256 colors)
Color Doppler (Color) (256 colors)
Directional color power Doppler (DCPD) (256 colors)
MMode
Pulsed wave (PW) Doppler
Continuous Wave (CW) Doppler
Tissue Harmonic Imaging
