Output Display
The system meets the AIUM output display standard for MI and TI (see last reference listed in
“Related Guidance Documents” below). Table 3 indicates for each transducer and operating mode
whether either the TI or MI is greater than a value of 1.0, thus requiring display.
Regardless that an MI of greater than 1.0 never occurs, the system provides a continuous real-time
display of MI whenever a transducer is operated in a 2D imaging mode. The index is displayed in
increments of 0.1.
The system meets the output display standard for TI. A continuous real-time display of TI is
provided for the operator whenever a transducer is operated in a CPD, DCPD, Color, M Mode, or
PW Doppler imaging mode. The index is displayed in increments of 0.1.
Table 3: Cases Where Either a Thermal or Mechanical Index is > 1.0
Transducer Model Index
2D/
MMode
CPD/DCPD
/Color
PW
Doppler
CW
Doppler
C8/8-5 MHz MI No No No –
TIC, TIB, TIS No Yes Yes –
C11/8-5 MI NoNoNoNo
TIC, TIB, or TIS No No Yes No
C15/4-2 MI NoNoNoNo
TIC, TIB, or TIS No Yes Yes No
C60/5-2 MI No No No –
TIC, TIB, or TIS No No Yes –
HST/10-5 MI No No No –
TIC, TIB, or TIS No No No –
ICT/8-5 MI No No No –
TIC, TIB, or TIS No No Yes –
L25/10-5 MI No No – –
TIC, TIB, or TIS No No – –
L38/10-5 MI No No No –
TIC, TIB, or TIS No No Yes –
