44 Chapter 3: Imaging
Imaging
The following table describes the transducer’s exam type, imaging mode, and optimization that may
be available with your system.
The optimization settings for 2D are Res, Gen, and Pen.
The optimization settings for color power Doppler (CPD), directional color power Doppler (DCPD),
and color Doppler (Color) are low, medium, and high (flow sensitivity) with a range of PRF settings
for Color depending on the application.
Sup Superficial
Vas Vascular
Table 1: Exam Type Abbreviations (Continued)
Abbreviation Exam Type
Table 2: Transducer, Exam Type, and Imaging Mode
Imaging Mode
Transducer Exam Type 2D THI CPD DCPD Color M Mode PW CW
C8 Prostate X X X X
Gyn X X X X
OB X X X X
C11 Vascular X X X X X
Cardiac X X X X X
Neonatal X X X X X
Abdomen X X X X X
C15 Abdomen X X X X X X
OB X X X X X X
Cardiac X X X X X X
C60 OB X X X X X X
Gyn X X X X X X
Abdomen X X X X X X
HST Superficial X X X X X
Muscle X X X X X
Vascular X X X X X
