Distance
Measurement
1 On a frozen 2D image, press the Caliper key.
A set of calipers is displayed on the screen and the following
on-screen menu options are available:
First caliper set
Second caliper set
Ellipse (circumference/area)
Delete
Note: The two calipers are connected by a dotted line. When the calipers get
close together, they decrease in size and the caliper line is removed.
Note: No additional calipers are available on Dual screens.
2 Use the touchpad to position the first caliper.
The active caliper is highlighted green.
3 Press the Select key to activate the second caliper.
4 Use the touchpad to position the second caliper.
The result is displayed in the measurement and calculation data area
and is updated as the caliper moves. The measurement is complete
when you finish moving the calipers.
5 If desired, press the Save key to save the image with the
measurements displayed.
Second Distance
Measurement
1 Press the Caliper key or select the second set of calipers from the
on-screen menu.
A second set of calipers is displayed. The active caliper is highlighted
green.
2 Use the touchpad and the Select key as described in the preceding
steps to complete the second measurement.
3 If desired, press the Save key to save the image with the
measurements displayed.
