A: Supplied wire rope
B: Supplied screw (M4×8)
C: Wire rope metal loop
Use the supplied screw. The use of a screw other than the supplied screw may reduce the effectiveness of the wire rope
function.
Note
It is recommended that one person holds the unit as shown in the following diagram while another person mounts the unit.
78
