Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
133
HCD-FL5D
1-683-901-11 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN712 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-598-69 IC BA6956AN
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
1-683-895-11 CONNECT BOARD
***************
< CONNECTOR >
CN701 1-568-860-11 SOCKET, CONNECTOR 17P
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R707 1-249-421-11 CARBON 2.2K 5% 1/4W
R708 1-249-417-11 CARBON 1K 5% 1/4W
R709 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
A-4676-890-A DSP BOARD, COMPLETE (EXCEPT AUS)
A-4730-231-A DSP BOARD, COMPLETE (AUS)
********************
< CAPACITOR >
C600 1-164-159-11 CERAMIC CHIP 0.1uF 50V
(AUS)
C601 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C602 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C603 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C604 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C606 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C607 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C608 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C609 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C610 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C611 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C612 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C613 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C614 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C615 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C616 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C617 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C618 1-126-934-11 ELECT 220uF 20% 10V
C619 1-126-934-11 ELECT 220uF 20% 10V
C621 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C623 1-126-934-11 ELECT 220uF 20% 10V
C633 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C634 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C635 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C636 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C637 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C638 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C639 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C640 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C641 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C642 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C644 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C645 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C648 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C649 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C650 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C651 1-126-934-11 ELECT 220uF 20% 10V
C652 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C653 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C654 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C655 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C656 1-126-933-11 ELECT 100uF 20% 16V
C657 1-126-933-11 ELECT 100uF 20% 16V
C659 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C660 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C661 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C662 1-126-934-11 ELECT 220uF 20% 10V
C663 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C664 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C665 1-126-934-11 ELECT 220uF 20% 10V
C666 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C668 1-126-934-11 ELECT 220uF 20% 10V
C671 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C672 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C673 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C689 1-126-933-11 ELECT 100uF 20% 16V
C690 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C697 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C698 1-126-959-11 ELECT 0.47uF 20% 50V
C699 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C701 1-126-964-11 ELECT 10uF 20% 50V
C702 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C703 1-126-964-11 ELECT 10uF 20% 50V
C704 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C708 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C709 1-126-960-11 ELECT 1uF 20% 50V
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-126-964-11 ELECT 10uF 20% 50V
C712 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C713 1-126-964-11 ELECT 10uF 20% 50V
CLAMP MOTOR CONNECT DSP
