Sony HCD-FL5D - DSP Board Parts

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
134
HCD-FL5D
C714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C715 1-126-964-11 ELECT 10uF 20% 50V
C716 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C718 1-126-964-11 ELECT 10uF 20% 50V
C719 1-126-964-11 ELECT 10uF 20% 50V
C720 1-126-964-11 ELECT 10uF 20% 50V
C721 1-136-165-00 FILM 0.1uF 5% 50V
C722 1-136-165-00 FILM 0.1uF 5% 50V
C723 1-126-964-11 ELECT 10uF 20% 50V
C725 1-126-964-11 ELECT 10uF 20% 50V
C726 1-126-964-11 ELECT 10uF 20% 50V
C730 1-126-964-11 ELECT 10uF 20% 50V
C731 1-126-947-11 ELECT 47uF 20% 10V
C732 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C733 1-126-947-11 ELECT 47uF 20% 10V
C734 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C735 1-126-947-11 ELECT 47uF 20% 10V
C736 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C741 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C743 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C747 1-126-960-11 ELECT 1uF 20% 50V
C748 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C749 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C751 1-126-964-11 ELECT 10uF 20% 50V
C752 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C753 1-126-964-11 ELECT 10uF 20% 50V
C754 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C758 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C759 1-126-960-11 ELECT 1uF 20% 50V
C760 1-126-964-11 ELECT 10uF 20% 50V
C761 1-126-964-11 ELECT 10uF 20% 50V
C762 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C763 1-126-964-11 ELECT 10uF 20% 50V
C764 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C765 1-126-964-11 ELECT 10uF 20% 50V
C766 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C768 1-126-964-11 ELECT 10uF 20% 50V
C769 1-126-964-11 ELECT 10uF 20% 50V
C770 1-126-964-11 ELECT 10uF 20% 50V
C771 1-136-165-00 FILM 0.1uF 5% 50V
C772 1-136-165-00 FILM 0.1uF 5% 50V
C773 1-126-964-11 ELECT 10uF 20% 50V
C775 1-126-964-11 ELECT 10uF 20% 50V
C776 1-126-964-11 ELECT 10uF 20% 50V
C781 1-126-934-11 ELECT 220uF 20% 10V
C782 1-164-360-11 CERAMIC CHIP 0.1uF 16V
(AUS)
C783 1-126-933-11 ELECT 100uF 20% 16V
C784 1-126-933-11 ELECT 100uF 20% 16V
C786 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C789 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C791 1-126-934-11 ELECT 220uF 20% 10V
C792 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C793 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN601 1-569-928-11 SOCKET, CONNECTOR 11P
CN602 1-784-780-11 CONNECTOR, FFC 19P
CN702 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
CN703 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
< DIODE >
D601 8-719-083-89 DIODE 11ES2N-TB5
D606 8-719-988-61 DIODE 1SS355TE-17
D611 8-719-988-61 DIODE 1SS355TE-17
D612 8-719-988-61 DIODE 1SS355TE-17
D741 8-719-988-61 DIODE 1SS355TE-17
D742 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
EP601 1-537-738-21 TERMINAL, GROUND
EP602 1-537-738-21 TERMINAL, GROUND
< SHORT/FERRITE >
FB601 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB601 1-414-772-21 FERRITE (AUS)
FB602 1-414-772-21 FERRITE (AUS)
FB611 1-216-864-11 SHORT CHIP 0
FB702 1-216-864-11 SHORT CHIP 0
FB703 1-216-864-11 SHORT CHIP 0
FB704 1-216-295-00 SHORT CHIP 0
FB708 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB710 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
FB711 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
< IC >
IC601 6-702-009-01 IC CXD9720Q
IC602 8-759-538-16 IC IS61LV6416-10TT (ISSI)
IC603 6-702-008-01 IC LC89057W-VF4-E
IC611 8-759-560-56 IC PCM1800E/2K
IC612 6-702-007-01 IC PCM1608Y/2K
IC621 8-749-019-26 IC TORX141 (OPTICAL DIGITAL IN)
IC622 8-749-019-25 IC TOTX141 (OPTICAL DIGITAL OUT)
IC631 8-759-835-63 IC NJM2391DL1-26 (TE1)
IC701 6-702-010-01 IC M61520FP
IC702 8-759-448-71 IC BU4053BCFV-E2
IC703 8-759-697-21 IC NJM4565V (TE2)
IC704 8-759-697-21 IC NJM4565V (TE2)
< JACK >
J701 1-766-396-11 JACK, PIN 4P (MD (VIDEO))
< RESISTOR >
JR602 1-216-864-11 SHORT CHIP 0 (EXCEPT AUS)
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR611 1-216-864-11 SHORT CHIP 0
JR612 1-216-864-11 SHORT CHIP 0
JR613 1-216-864-11 SHORT CHIP 0
JR614 1-216-864-11 SHORT CHIP 0
JR615 1-216-864-11 SHORT CHIP 0
DSP
