Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
154
HCD-FL5D
< SHORT >
JR214 1-216-864-11 SHORT CHIP 0
**************************************************************
1-684-199-11 TC DOOR SW BOARD
******************
< SWITCH >
S325 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(CASSETTE LID OPEN/CLOSE DETECT)
**************************************************************
1-684-200-11 TC SW (A) BOARD
***************
< RESISTOR >
R338 1-216-825-11 RES-CHIP 2.2K 5% 1/10W
< SWITCH >
S326 1-771-410-21 SWITCH, TACTILE (A Z)
**************************************************************
A-4730-184-A TRANS BOARD, COMPLETE (SP)
A-4730-188-A TRANS BOARD, COMPLETE (MX)
A-4730-190-A TRANS BOARD, COMPLETE (EA)
A-4730-203-A TRANS BOARD, COMPLETE (AUS)
A-4730-213-A TRANS BOARD, COMPLETE (TH)
**********************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C913 1-128-576-11 ELECT 100uF 20% 63V
C914 1-126-960-11 ELECT 1uF 20% 50V
C915 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
* CN914 1-564-522-11 PLUG, CONNECTOR 7P
* CN915 1-564-521-11 PLUG, CONNECTOR 6P
* CN916 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D911 8-719-083-89 DIODE 11ES2N-TB5
D912 8-719-983-96 DIODE MTZJ-T-72-39A
D913 8-719-160-29 DIODE RD6.2F-T7B2
D914 8-719-109-68 DIODE MTZJ-T-72-3.6A
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
0 R913 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
R914 1-249-417-11 CARBON 1K 5% 1/4W
R915 1-249-429-11 CARBON 10K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
1-684-692-11 VIDEO BOARD
************
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20% 10V
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-126-965-11 ELECT 22uF 20% 50V
C704 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-164-159-11 CERAMIC 0.1uF 50V
C742 1-126-935-11 ELECT 470uF 20% 6.3V
C743 1-104-665-11 ELECT 100uF 20% 10V
C744 1-126-935-11 ELECT 470uF 20% 6.3V
C745 1-104-665-11 ELECT 100uF 20% 10V
C746 1-126-935-11 ELECT 470uF 20% 6.3V
C747 1-104-665-11 ELECT 100uF 20% 10V
C748 1-104-665-11 ELECT 100uF 20% 10V
C749 1-126-965-11 ELECT 22uF 20% 50V
C750 1-104-665-11 ELECT 100uF 20% 10V
C751 1-126-965-11 ELECT 22uF 20% 50V
C761 1-126-960-11 ELECT 1uF 20% 50V
C762 1-126-960-11 ELECT 1uF 20% 50V
C763 1-126-960-11 ELECT 1uF 20% 50V
C764 1-126-960-11 ELECT 1uF 20% 50V
C765 1-126-960-11 ELECT 1uF 20% 50V
C766 1-126-960-11 ELECT 1uF 20% 50V
C780 1-162-207-31 CERAMIC 22PF 5% 50V
C781 1-162-207-31 CERAMIC 22PF 5% 50V
C782 1-162-207-31 CERAMIC 22PF 5% 50V
C784 1-162-207-31 CERAMIC 22PF 5% 50V
C785 1-162-207-31 CERAMIC 22PF 5% 50V
C786 1-162-207-31 CERAMIC 22PF 5% 50V
< CONNECTOR >
CN701 1-816-590-11 CONNECTOR 17P
< IC >
IC701 6-702-335-01 IC MM1568
< JACK >
J701 1-793-445-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J702 1-537-943-11 TERMINAL, S (S VIDEO OUT)
J703 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L701 1-410-470-11 INDUCTOR 10uH
< TRANSISTOR >
Q711 8-729-422-57 TRANSISTOR BN1A4M-TP
Q712 8-729-900-89 TRANSISTOR BA1L4M-TP
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-429-11 CARBON 10K 5% 1/4W
R717 1-247-804-11 CARBON 75 5% 1/4W
R718 1-247-804-11 CARBON 75 5% 1/4W
R719 1-247-804-11 CARBON 75 5% 1/4W
TC DOOR TC DOOR SW TC SW (A) TRANS VIDEO
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
