Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
155
HCD-FL5D
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-804-11 CARBON 75 5% 1/4W
R724 1-249-429-11 CARBON 10K 5% 1/4W
R725 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
MISCELLANEOUS
**************
53 1-773-044-11 WIRE (FLAT TYPE) (17 CORE)
110 1-773-032-11 WIRE (FLAT TYPE) (15 CORE)
158 1-823-861-11 WIRE (FLAT TYPE) (8 CORE)
301 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
302 1-824-686-11 WIRE (FLAT TYPE) (13 CORE)
303 1-773-123-11 WIRE (FLAT TYPE) (19 CORE)
304 1-773-105-11 WIRE (FLAT TYPE) (19 CORE)
308 1-773-049-11 WIRE (FLAT TYPE) (17 CORE)
310 1-824-652-11 WIRE (FLAT TYPE) (29 CORE)
352 1-792-099-11 WIRE (FLAT TYPE) (17 CORE)
353 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
358 1-693-572-21 TUNER (FM/AM)
0 453 1-569-008-21 ADAPTOR, CONVERSION (EA, SP)
0 455 1-777-071-83 CORD, POWER (EA, SP)
0 455 1-783-203-12 CORD, POWER (AUS)
0 455 1-791-901-21 CORD, POWER (MX, TH)
0 703 A-4713-410-A OPTICAL TRAVERSE UNIT (DBU-1)
705 1-824-106-12 CABLE, FLEXIBLE FLAT (24 CORE)
0 F913 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
(EA, MX, SP)
0 F914 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0 F915 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0 F916 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0 F917 1-576-655-11 FUSE, GLASS TUBE (DIA. 5) (8A/250V)
0 F918 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) (6.3A/250V)
0 F919 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) (5A/250V)
HP901 A-2004-765-A BASE (A) ASSY, HEAD (PB)
(for TCM-230PWR41CS)
HP901 X-4953-985-1 BLOCK (A) ASSY, HEAD (PB)
(for TCM-230AWR41CS)
HRPE901A-2004-766-A BASE (B) ASSY, HEAD (REC/PB/ERASE)
(for TCM-230PWR41CS)
HRPE901X-4953-986-1 BLOCK (B) ASSY, HEAD (REC/PB/ERASE)
(for TCM-230AWR41CS)
IC801 6-701-760-01 IC UPC3504AHF
IC802 8-759-231-53 IC TA7805S
IC803 8-759-231-57 IC TA7810S
IC804 8-759-231-53 IC TA7805S
IC921 8-759-518-68 IC PQ12RF21
IC922 8-759-701-59 IC TA7809S
M301 1-763-790-11 MOTOR, DC (CD DOOR OPEN/CLOSE)
M701 X-4950-341-1 MOTOR (CLAMP) ASSY
M702 X-4950-342-1 MOTOR (LOADING) ASSY
M801 1-763-488-51 FAN, DC
M901 X-3378-241-1 MOTOR ASSY (CAPSTAN) (WITH PULLEY)
(TAPE) (for TCM-230AWR41CS)
M901 X-3378-241-1 MOTOR ASSY (CAPSTAN) (WITH PULLEY)
(for TCM-230PWR41CS)
PM901 1-454-887-21 SOLENOID, PLUNGER
(for TCM-230PWR41CS)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
PM902 1-454-887-21 SOLENOID, PLUNGER
(for TCM-230PWR41CS)
S707 1-418-045-01 ENCODER, ROTARY
(DISK TRAY ADDRESS DETECT)
0 T911 1-437-800-11 TRANSFORMER, POWER (AUS, MX, SP, TH)
0 T911 1-437-801-11 TRANSFORMER, POWER (EA)
************************************************************
VIDEO
Ver 1.4
