Sony MHC-V41D Service Manual

MHC-V41D
36
10. When the operation of swiping on the gesture control sensor,
shown in the following fi gure, will appear display correspond-
ing to the operation.
Note: Do not touch or contact to the gesture control sensor when you per-
form the swiping motion.
Screen display (Right to left) Screen display (Left to right)
Screen display (Bottom to top) Screen display (Bottom to top)
(Displayed characters in the above fi gure are example)
Releasing method:
Press two buttons of the [
x] and [MIC/GUITAR LEVEL –] simul-
taneously for 3 seconds, and return to the normal mode.
SHOP FRONT DEMO
The demo mode can be performed.
(This mode is used by shop front)
Procedure:
1. Press the [
1
] button to turn the power on.
2. Press the [FUNCTION] button to select the “DVD/CD” or
“USB” function, and set the media according to the function.
3. Press two buttons of the [x] and [MIC ECHO] simultaneously
for 5 seconds.
4. The message “AutoPLAY” is displayed on the vacuum fl uo-
rescent display.
Screen display
5. Press the [– TUNING .] or [TUNING + >] button to
select either “AutoPLAY” or “AutoSTOP” in the demo mode,
then press the [
N] button to decision.
Screen display
or
6. The message “10 MIN” is displayed on the vacuum fl uorescent
display.
Screen display
7. Press the [– TUNING .] or [TUNING + >] button to
auto play or auto stop timer value (01 MIN to 20 MIN) setting,
then press the [N] button to decision.
8. This unit is rebooted. It enters the demo mode, “* DEMO *”
and current function state are alternately displayed on the vac-
uum fl uorescent display.
(When the “AutoPLAY” has been selected in step 5, playback
starts automatically)
Screen display
current function state display
9. When the “AutoPLAY” has been selected in step 5, even if
stopping the playback, playback starts automatically after the
setting time.
When the “AutoSTOP” has been selected in step 5, even if
starting the playback, playback stops automatically after the
setting time.
(Even if pressing the [
Z
] button, the disc tray is locked and
cannot be opened)
Releasing method:
Press two buttons of the [x] and [MIC ECHO] simultaneously for
5 seconds.
Note: The demo mode does not release by unplug the power supply cord.

Sony MHC-V41D Specifications

General

Cassette deck	No
Product color	Black
Number of decks	1 deck(s)
Disc loading type	Tray
Optical disc player	Yes
Number of optical discs	1 discs
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Number of microphone inputs	2
Audio decoders	Dolby Digital
RMS rated power	- W
Woofer diameter	250 mm
Tweeter diameter	40 mm
Number of speakers	1
Mid-range driver diameter	80 mm
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-RW
Playback disc formats	DVD-Video, VCD
Audio formats supported	MP3
Video formats supported	MPEG4, XVID
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	20
Power source	AC
Power consumption (standby)	0.5 W

Weight and Dimensions

Depth	308 mm
Width	328 mm
Height	796 mm
Weight	13500 g
