206
Basic Procedure for Wipe Settings
Chapter 5 Wipes
a) See page 211.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 210.
• When turning [Angle] on in the <Rotation> group and slanting the
pattern
a) See page 208.
• When turning [Speed] on in the <Rotation> group and rotating the
pattern at a constant rate
a) See page 209.
6
To adjust color 1, set [Color 1] on, and to adjust color 2 set [Color 2] on,
then adjust the parameters.
7
To interchange color 1 and color 2, press the [Color Invert] button, turning
it on.
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
