Space ER232R - Wheel Balancing in Motorbike Mode

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 39 of 58
Fig. 65
End section of distance threaded
arm for motorbike wheels
Distance extension for
motorbike wheels
End part of non-thread-
ed arm for motorbike
wheels
1296-M010-0_P
Space s.r.l.
ER232R - ER234R - ER236R - ER238R - ER238RFM - ER248R - ERP248R
16.0 WHEEL BALANCING IN MOTOR-
BIKE MODE
By enabling the “Motorbike wheel balancing” function
(see Fig. 89) the wheel balancers can also balance
motorbike wheels.
From the opening page, press the “F2 key” to select
car (Fig. 63) or motorcycle (Fig. 64) balancing mode.
Fig. 63
Fig. 64
The "Motorcycle" mode automatically recalculates the
wheel distance measurement, increasing this by the
length of the optional extension GAR181A1.
To fit the distance extension, the old non-threaded end
part of the arm must be removed and the threaded
one fitted (see Fig.Fig. 65). The extension will only
have to be screwed up when balancing is performed
in "Motorbike" mode.
