22.0 ERROR SIGNALS
During wheel balancer operation, if wrong commands are given by the operator or device faults occur, an error
code or symbol may appear on the display screen. Press key F1
to return to the previous program
phase after remedying the fault. Below is a troubleshooting chart.
Error
code
Error description Cause
1 Carter error
During the balancing procedure, the protection guard appears open.
If the guard is correctly closed, the detection micro or acquisition
board may be faulty.
THE CYCLE CAN IN ANY CASE BE PER-
FORMED, CUTTING OUT THE OPEN GUARD
CONTROL, BY PRESSING THE F4+CENTR.
KEYS SIMULTANEOUSLY. THIS OPERATION
MUST BE PERFORMED IN MAX SAFETY
CONDITIONS, WITHOUT MOVING ANYTHING
CLOSE UP TO THE ROTATING PARTS.
2 No rotation signal
Faulty position transducer or transducer not fitted correctly.
The motor is faulty or has not started because something is pre-
venting its rotation.
3
Excessive weight value in
wheel balancer calibration
During the calibration procedure, the machine detects excessive
weight.
- The weight may not have been fitted properly.
- The data acquisition or measurement sensor may be faulty.
8
Insufficient weight value in
wheel balancer calibration
During the calibration procedure, the machine detects insufficient
weight.
- The weight may not have been fitted properly.
- The data acquisition or measurement sensor may be faulty.
9
Calibration spin not com-
pleted
During the calibration procedure, the spin is not completed because
the key has been pressed (STOP).
10
Pneumatic mandrel error
(only for ERP248R model)
During the balancing procedure, the pneumatic mandrel is open.
Close the mandrel before starting the spin. If necessary, switch the
machine off and on. If the error continues, the micro on the pedal
or the acquisition board could be faulty.
11
Diameter sensor calibration/
width value out of range
During the diameter potentiometer calibration/width procedure,
the machine detects an out-of-range value. The rod may not have
been positioned properly; the sensor data acquisition board may
be faulty.
12 Distance/Diameter Error
During the balancing operation, the rod is not in idle position. Turn
the machine off and on with the rod in correct idle position. If the
error persists, the distance or diameter sensor or else the data
acquisition board could be faulty.
