10083002 Operator Manual Symbol Definitions
Consult instructions before use
Hot, Potential Burn Hazard
Potential Impact Hazard
Maximum Load Hazard (maximum load limit given on label)
Ambient Light Control – ON/OFF (Control Center)
Do not operate system unless optical fiber cables are fully connected
Press key to access System Menu for system configuration or information
Indicates control fault. Refer situation to qualified, trained service technician
Serial Number of Unit
V~ Voltage Rating of Unit, Alternating Current
A Amperage Rating of Unit, Alternating Current
Hz Frequency Rating of Unit, Alternating Current
Increase Intensity (Surgeon's Control Buttons)
a
Table 2-1. Symbol Definitions
Symbol Definition
