5-19
Operating Instructions Operator Manual 10083002
NOTE: If two or more camera modules are installed on a system,
none of the cameras will energize.
Once the video camera module has been installed in the lighthead,
the camera may be turned on at the control center by selecting the
camera menu and then selecting camera on. Once the camera is
initialized, full control of all camera functions is available through
menus on the control center. The list of camera features and how
they may be controlled is summarized in the Table 5-3.
* The number shown is the number of the camera control menu on the wall-
mounted control center. See Figure 5-16 for camera control screens 1 and 2;
and Figure 5-17 for camera control screens 3 and 4.
Table 5-3. Camera Functions
Control Center
Feature
Camera
Control
Menu*
Power 1
Zoom 1
Rotate 1
Auto/Manual Brightness 1
Brightness 1
Auto/Manual Focus 1
Focus 1
Auto/Manual White Balance 2
Red-Gain 2
Blue-Gain 2
Live/Freeze Picture 2
Zoom Speed 4
Focus Speed 4
