Steris Harmony LED Wall Control Unit - 5.12.2 HD Settings; Table 5-5. Camera Control Screen 4 - HD Video Signal Adjustment Operation

5-24
10083002 Operator Manual Operating Instructions
5.12.2 HD Settings When a high definition (HD) camera is installed in the system, the
video signal scan frequency and resolution can be adjusted (see
Table 5-5).
f
Camera speed adjustment remains the same as for a standard
definition video system (see Table 5-4).
When adjusting scan frequency or resolution, changes take effect
when the user exits Camera Control Screen 4. Upon exiting
Screen 4, camera power cycles off then on and the new setting takes
effect.
NOTE: Exiting Camera Control Screen 4 using the Camera Menu
button, causes wall control to display Camera Control Screen 1.
“INITIALIZING CAMERA” message replaces “IDENTIFYING
CAMERA” message on Camera Control Screen 1.
Table 5-5. Camera Control Screen 4 – HD Video Signal Adjustment Operation
Row Selected
Key
Press
Operation
HD SETTING (with row identification text) LEFT HD camera scan frequency is set to 50Hz.
HD SETTING (with row identification text) RIGHT HD camera scan frequency is set to 60Hz.
HD SETTING (without row identification text) LEFT HD camera resolution is set to 1080i.
HD SETTING (without row identification text) RIGHT HD camera resolution is set to 720p.
