5 Operation
Battery
Installing the engine cover
Lift in the engine cover.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
– Only lift up and position the covers using two
people.
Lift in the engine cover.
– To do this, fold up the handles of the engine
cover.
– Lift in the battery cover with help from
another person.
Position and close the engine cover.
– To do this, align and position the engine
cover.
– Fold in the handles.
– Ensure that the engine cover is closed
correctly.
Battery cables
CAUTION
There is a possibility of damage to the battery
cables during operation or transportation.
Regardless of whether the battery male connector
is connected or disconnected, always route the
battery cables in a way that ensures they cannot be
crushed, abraded or cut.
90 1
72780 EN - 06/2017
