5 Operation
Checks and tasks to be carried out pr
ior to commissioning
6321_003-041
7
Switching the seat heater (variant) on
and off
NOTE
The seat heater only functions if the seat
contact switch is active, i.e. when the driver is
sitting on the driver's seat.
– Switch the seat heater (7) on or off using the
switch.
127-130
Top up the screen wash reservoir
CAUTION
The washer system can be damaged!
If there is no anti-freeze in the system, the washer
system can be damaged.
– Always use washer fluid containing anti-freeze.
The reservoir for the front and rear screen
wash fluid is location behind the seats.
– Fold the seat completely forwards.
– Open the filler cap on the screen wash
reservoir.
– Top up the screen wash reservoir with
washer fluid and anti-freeze according to
manufacturer specifications.
– Close the filler cap on the screen wash
reservoir.
58 1
72780 EN - 06/2017
