5 Operation
Drive mode
The parking brake is released and the warning
light for the applied parking brake goes out on
the display unit.
NOTE
The parking brake engages if the driver leaves
the seat.
NOTE
The parking brake engage
s if the emergency
stop switch is pressed.
NOTE
The truck brakes regeneratively if the parking
brake button is pressed when travelling. The
driver must also brake the truck hydraulically
by operating the foot brake pedal - the parking
brake is only applied once the vehicle is
stationary.
NOTE
As an option, the
button can be arranged on
the left-hand si
de of the steering column
Driving the truck
in reverse
– Pull down the operating lever (1) on the
right-hand side of the steering column.
The reverse arrow symbol illuminates on the
display unit.
NOTE
As an option, the operating lever can be
located on the left-hand side of the steering
column
80 1
72780 EN - 06/2017
