Operation 5
Commissioning
Checking the automatic tow co
upling
(variant)
WARNING
Risk of being trapped and crushed!
– Before carrying out any maintenance work on
the coupling, ensure that the coupling is closed.
– Do not reach into the open coupling.
NOTE
If the coupling is engaged and disengaged
more than 2-3 times per shift, the coupling
must be relubricated on the lubricating nipple.
– Check the coupling
pin (1) for damage.
– Clean any dirt from the coupling.
– Relubricate the coupling at the lubricating
nipple.
– Ensure that the co
upling pin engages in the
locating hole (2
).
172
780 EN - 06/2017 69
