Operation 5
Display unit
1
Parking brake indicator
– Parking brake indicator (1) illuminates in the
display unit.
Parking brake is activated.
Display plain text messages
In the event of the driver making an operating
error, plain text messages are shown on the
display. Message texts are displayed in the
set display language.
Plain text messages on the display
Message text
Comment
Batt
Battery door open (truck not driving) or battery deeply discharged
(truck in emergency operation). Only for platform tractors.
Dir
No drive direction signal with accelerator actuated and parking
brake released
FBr
The drive direction was selected and the accelerator actuated with
the foot brake pressed down
HBr
The drive direction was selected and the accelerator actuated with
the parking brake actuated
HB1
The accelerator was actuated whilst the inching function was active
No Can
Can bus not active (truck not working)
Sit
The drive direction was selected and the accelerator actuated
whilst the seat switch was not actuated
.
172
780 EN - 06/2017 111
