6 Maintenance
Servicing
Servicing
Fuses
Fuses (generation 1)
Located under the bottom plate below the
driver, accessible through a cutout.
Signal horn
4F1 10 A
Switch relay for the
sidelights/headlights
5F1 10 A
Left-hand sidelights
5F2 10 A
Right-hand sidelights 5F3 10 A
Main beam headlights 5F4 10 A
Dipped beam headlights 5F5 10 A
Brake lights 5F6 10 A
Rear fog lights
5F7 10 A
Reversing lights 5F8 10 A
Lever and relay for the
direction indicator
5F9 10 A
Relay for the direction
indicator and turn indicator
5F10 10 A
Rotating beacon 5F11 10 A
Interior light 5F12 10 A
Working spotlights 5F13 10 A
Front windscreen
wiper/washer
(resettable)
9F1 8 A
Rear window wiper/washer 9F2 10 A
Radio cassette 9F3 10 A
Heated seat 9F5 10 A
Relay module for the cab
heater
9F6 10 A
.
174
172780 EN - 06/2017
