Maintenance 6
Providing access to maintenance po
ints
Installing the engine cover
Lift in the engine cover.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
– Only lift up and position the covers using two
people.
Lift in the engine cover.
– To do this, fold up the handles of the engine
cover.
– Lift in the battery cover with help from
another person.
Position and close the engine cover.
– To do this, align and position the engine
cover.
– Fold in the handles.
– Ensure that the engine cover is closed
correctly.
172
780 EN - 06/2017 173
