6 Maintenance
Providing access to maintenance po
ints
Removing the engine cover (platform
tractors)
Open and lift the engine cover
.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
– Only lift up and position the covers using two
people.
Open and lift the engine cover.
– To do this, fold up the handles of the engine
cover.
– Lift the engine cover with help from another
person.
Lift out the engine cover.
– To do this, lift out the engine cover with help
from another second person.
– Remove the engi
ne cover from the working
area.
– Ensure that no parts can fall into the engine
compartment.
172
172780 EN - 06/2017
