Maintenance 6
Providing access to maintenance po
ints
Installing the battery cover (platform
tractors)
Lift in the battery cover.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
– Only lift up and position the covers using two
people.
NOTE
On the cab version with sliding doors, the
sliding doors must be closed.
Lift in the battery cover.
– Todothis,foldupt
he handles of the battery
cover.
– Lift in the battery cover with help from
another person.
Position and close the battery cover.
– To do this, align a
nd position the battery
cover.
– Fold in the handles.
– Ensure that the battery cover is closed
correctly.
172
780 EN - 06/2017 171
