6 Maintenance
Providing access to maintenance po
ints
Removing the battery cover (platform
tractors)
Open and lift the battery cove
r.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
– Only lift up and position the covers using two
people.
NOTE
On the cab version with sliding doors, the
sliding doors must be closed.
Open and lift the battery cover.
– To do this, fold up t
he handles of the battery
cover.
– Lift the battery cover with help from another
person.
Lift out the batter
y cover.
– To do this, remove the battery cover from
the working area.
– Ensure that no parts can fall into the battery
compartment.
170
172780 EN - 06/2017
