Operation 5
Display unit
Warning indicator for the int
erlock
– Interlock warning indicator
(1) illuminates in
the display unit.
Interlocked or locked function is actuated.
– Check that the key switch is working cor-
rectly.
– Check that the emergency o
ff switch is
working correctly.
– Check that the parking brake is working
correctly.
– Check that the back pedal is working
correctly.
– Check that the seat swit
ch is working
correctly.
– Check that the interlock switch for the
battery door (only on the platform version)
is working correctly.
– Check that the remotely unlockable tow
coupling (variant) is working correctly.
NOTE
Additional interlock switches may be fitted for
any attachments. These switches must be
checked for correct and safe operation.
Display unit screen
The screen of the display unit (1) displays
operating states and values.
(2) Speed in miles/h or km/h (lights
up simultaneously with (3) or (4)
to display the speed in miles per hour
or km per hour to display).
(3)
Route travelled in kilometres.
(4)
Routetravelledinmiles.
(5) Time *.
(6)
Hour meter.
* Variant only in combination with data logger
172
780 EN - 06/2017 113
