Operation 5
Battery
CAUTION
Risk of battery damage from battery tipping over!
– Only store the battery on a suitable beam support
or on suitable racking.
– Do not store the battery on a wooden beam or
similar.
– Carefully drive the hand pallet stacker truck
under the battery.
– Raise the battery suffici
ently to clear the
locating blocks on the ch
assis.
– Carefully remove the battery from the
battery compartment.
Transporting and setting down the
battery
WARNING
Risk of accident due to improper means of trans-
port!
The load capacity of the hand pallet truck in use
must at least match the battery weight (see battery
identification plate).
WARNING
Increased risk of accident when transporting with
lack of care!
– If the battery is to be replaced using a hand pallet
truck, this must only be done on level ground.
– Always drive at low speed.
– Do not traverse slopes with a battery placed on
the hand pallet truck truck.
– Always avoid sharp corners.
– Slowly remove battery from battery com-
partment.
–Care
fully transport battery to the intended
stor
age space.
Ins
talling the battery
DANGER
Increased risk of crushing and shearing between
battery and chassis!
– Do not reach between the battery and chassis.
172
780 EN - 06/2017 101
