Maintenance 6
Providing access to maintenance po
ints
Closing the battery cover
Release the battery cover.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
Release the battery cover.
– To do this, push the safety stay (1) over
the security bolt (2) until the safety stay is
released.
– Slowly lower the battery cover; to do so,
release the safety stay.
Lower the
battery cover.
– Todothis,pushdownthebatterycoverwith
both hands.
172
780 EN - 06/2017 167
