6 Maintenance
Servicing
Removal
– Park the truck securely.
– Switch off the key switch.
– Disconnect the battery.
– Block the front wheels.
– Loosen the wheel bolts - DO N
OT remove
the wheel bolts.
– Place the hydraulic jack underneath the rear
undercarriage plate at the locations shown.
– Raise the truck from the floor until the
wheels are no longer in contact with the
ground.
– Remove wheel bolts.
– Remove wheel.
Installation
– Insert wheel.
– Tighten the wheel bolt
s crosswise.
– Carefully lower the truck.
– Remove the hydraulic jack.
– Tighten the wheel bolt
s crosswise with a
torque of 195 Nm.
– For safety reasons, the correct assembly of
the wheel bolts MUST be checked after 50
operating hours.
NOTE
If the wheel bolts need re-tightening to the
correct torque, they must then be checked
again after 50 operating hours.
190
172780 EN - 06/2017
