Technical data 7
Technical data — platform truck (26
00)
Dimensions – platform tractor (2 600)
4.16
Loading platform, length
l
3
(mm)
2600
4.17
Rear overhang
l
5
(mm)
1130
4.18
Loading platform, width
b
9
(mm)
1300
4.19
Overall length
l
1
(mm)
3930
4.21 Overall width b
1
(mm)
1300
4.32
Ground clearance, centre of wheelbase
m
2
(mm)
150
4.35
Turning radius
W
a
(mm)
3280
4.36
Minimum pivoting point
distance
b
13
(mm)
1095
Performance – platform tractor (2 600)
5.1
Travel speed, with/without rated drawbar pull
km/h
5kW=15/20
20 kW = 20/20
5.5
Drawbar pull at 60 minute rating, with/without load on
platform
N
5kW = 500/900
20kW = 800/1200
5.4
Maximum drawbar pull, with/without load on platform
(Based on level, dry surface with rolling resistance of
200 N/t)
Refer to towing capacity diagram for specific oper-
ating conditions and when the application involves
inclines or ramps.
N
5kW = 5600/6000
20kW = 9600/10000
5.7
Climbing ability, with/without load, 30 minute rating
%
See graph
5.8
Maximum climbing ability, with/without load, 5 minute
rating
%
See graph
5.10
Service brake
Hydraulic/electric
Drive – platform t
ractor (2 600)
6.1
Drive motors, 60 minute rating
20 kW version is only available in conjunction with
320 Ah battery
kW
5kW = 2 x 2.5
20kW = 2 x 10
6.3
Battery according to DIN 43531/35/36 A, B, C, no
DIN 43536A
6.4
Battery voltage/rated capacity (5h)
20 kW version is only available in conjunction with
320 Ah battery
V/Ah 80/320
6.5
Battery weight (±5%) kg
858
6.6
Power consumption according to VDI cycle
kW/h
Refer to manufac-
turer
172
780 EN - 06/2017 217
