5 Operation
Battery
Secure the engine cover in the lifted position.
– To do this, release the suppor
t rod (1) from
the holder (in the engine cove
r).
– Latch the support rod in the safety plate (2)
such that the support rod is locked in place
and secured.
– Ensure that the engine cover is secured
against falling shut unintentionally.
Closing the engine cover
Release the engine c
over.
WARNING
Risk of crushing!
When lifting and closing, limbs could become
trapped.
– Do not reach between covers and chassis.
Release the engine cover.
– To do this, unlatch the support rod (1) from
the safety plate (2) and position the support
in the holder (in the engine cover).
Close the engi
ne cover.
– To do this, press down the engine cover
against the pressure of the gas spring and
hold the engine cover closed.
– Tighten the locking screw (1) by turning the
screw clockwise.
– Ensure that the
engine cover is closed
correctly.
86 1
72780 EN - 06/2017
