RX70-40 RX70-45 RX70-50 RX70 50/600
Track width: front twin tyre
b 10
(mm)
1364 1364 1364 1364
Track width: rear
b 11
(mm)
1120 1120 1120 1120
Basic dimensions
RX70-40 RX70-45 RX70-50
RX70
50/600
Lift mast/fork carriage tilt,
forwards/backwards
Degrees 3/7 3/7 3/7 3/7
Height with lift mast retrac-
ted
h1 (mm) 2400 2400 2400 2400
Free lift h2 (mm) 160 160 160 160
Lift height h3 (mm) 3180 3180 3180 2980
Height with lift mast exten-
ded
h4 (mm) 4187 4187 4187 4137
Height above overhead
guard
h6 (mm) 2300 2300 2300 2300
Seat height h7 (mm) 1298 1298 1298 1298
Coupling height
h10
(mm)
496 496 496 496
Overall length l1 (mm) 4027 4071 4198 4368
Length from Fork back l2 (mm) 3027 3071 3098 3168
Overall width b1 1380 1506 1506 1506
Fork arm dimensions
s/e/l
(mm)
50/120/1000 50/120/1000 50/120/1000 50/210/1200
Fork carriage according to
ISO 2328 class/form A, B
Category III /
Form A
Category III /
Form A
Category
III / Form A
Category III /
Form A
Fork carriage width b3 (mm) 1310 1310 1410 1310
Ground clearance with load
below lift mast
m1 (mm) 140 140 140 140
Ground clearance at the
middle of the wheelbase
m2 (mm) 165 165 165 165
Aisle width for pallets 1000
x 1200 crosswise
Ast
(mm)
4401 4441 4470 4539
Aisle width for pallets 800 x
1200 lengthwise
Ast
(mm)
4601 4641 4670 4739
Technical data
6
VDI datasheet
35557348011850 EN - 08/2020 - 12
