Still RX70-40 - Four-Way Mini-Lever

Four-way mini-lever
7325_003-027
1
2
3
4
5
6
7
8
9
"Lift/lower" operating lever
"Tilt" operating lever
Function key "F1"
Function key "F2"
"Drive direction/turn indicator" cross lever
1
2
3
4
5
Function key "5th function"
"Auxiliary hydraulics 1" operating lever
"Auxiliary hydraulics 2" operating lever
Signal horn button
6
7
8
9
NOTE
Depending on the specification, various elec-
tric attachment parts can be controlled via
function keys (3) and (4).
●
For alterations, contact the authorised serv-
ice centre.
Overviews
3
Operating devices and display elements
