Installation and commissioning
Instructions for use • AIDA C WD310 • AAB272_EN_V2.0_12-2021_IFU_CE-MDR 37
2. If a one-pedal footswitch is connected, deactivate the
Right Full Press, Right Half Press
operating options using the
None
setting.
Setting Meaning
Still capture Channel 1 Source 1 still capture
Still capture Channel 2 Source 2 still capture
Still capture channels 1 and 2 One still capture from source 1 and source 2
at the same time
Video start / stop Channel 1 Start or stop the video recording from source
1
Video start / stop Channel 2 Start or stop the video recording from source
2
Video start / stop Channels 1 and 2 Start or stop a video recording from source 1
and source 2 at the same time
None No function
Remote control via camera head buttons
1. If a foot pedal is connected, start by setting up the foot pedal.
ð The connections for the two camera head buttons are defined.
2. Connect the camera head buttons to the desired serial ports. Make sure that the camera
head buttons and footswitch are operated in the same way.
Connection Meaning
ACC1 Left full press, left pedal full press
ACC2 Left half press, left pedal half press
ACC3 Right half press, right pedal half press
ACC4 Right full press, right pedal full press
6.1.3.5 Voice control
The
Voice Control
tab is used to trigger image capturing and video recording with predefined
commands. An activation word, which is specified on the tab, must be prefixed to the
command.
