Electromagnetic compatibility
Instructions for use • AIDA C WD310 • AAB272_EN_V2.0_12-2021_IFU_CE-MDR 97
– DVI-D Single Link
– Full HD 1920*1200 pixels
– 60Hz
– Molded connectors
– Double shielding
– Integrated ferrite core, 2x
10.3 Table 1 – Compliance level for immunity tests
Guidelines and manufacturer’s declaration– electromagnetic immunity
The product is intended for use in the electromagnetic environment specified below. The user
of the product should make sure that it is used in such an environment.
Interference im-
munity tests
EN/IEC60601 test
level
Compliance level Electromagnetic envi-
ronment – guidelines
Electrostatic dis-
charge (ESD) acc.
to IEC61000-4-2
±8kV contact dis-
charge
±15kV air discharge
±8kV contact dis-
charge
±15kV air discharge
Floors should be made
of wood, concrete, or
covered with ceramic
tiles. If floors are cov-
ered with synthetic ma-
terial, the relative hu-
midity must be at least
30%.
Electrical fast
transients/bursts
acc. to IEC
61000-4-4
±2kV for power lines
±1kV for input and
output lines
100kHz repetition
±2kV for power lines
±1kV for input and
output lines
100kHz repetition
The power supply qual-
ity should be that of a
typical commercial or
hospital environment.
Surges acc. to
IEC 61000-4-5
± 1kV voltage outer
conductor – outer con-
ductor
± 2kV voltage outer
conductor – ground
± 1kV voltage outer
conductor – outer con-
ductor
± 2kV voltage outer
conductor – ground
The power supply qual-
ity should be that of a
typical commercial or
hospital environment.
Voltage dips,
short interrup-
tions, and voltage
variations acc. to
IEC61000-4-11
Voltage dip:
Dip to 0% for 1 cycle
at 0° phase angle
Dip to 70% for 25/30
cycles at 0° phase an-
gle
Dropout to 0% for 0.5
cycles @ 0°, 45°, 90°,
135°, 180°, 225°, 270°,
and 315° phase angles
Voltage interruption:
100% for 250/300cy-
cles
Voltage dip:
Dip to 0% for 1 cycle
at 0° phase angle
Dip to 70% for 25/30
cycles at 0° phase an-
gle
Dropout to 0% for 0.5
cycles @ 0°, 45°, 90°,
135°, 180°, 225°, 270°,
and 315° phase angles
Voltage interruption:
100% for 250/300cy-
cles
The power supply qual-
ity should be that of a
typical commercial or
hospital environment. If
the user of the product
requires continued op-
eration in the event of
interruptions to the
power supply network,
it is recommended that
the product be oper-
ated with an uninter-
ruptible power supply
or a battery.
