02.11
Strapex SMA 20
57
Pos. Artikel-Nr. Benennung Part name Article Articolo Stück
Part no Quantity
No d'article
Pièce
Art. no Pezzi
38 1835.021.357 Kurvenscheibe K 1 Cam K 1 Disque à came K 1 Disco a camme completo K1 1
39 1835.021.358 Kurvenscheibe K 2 Cam K 2 Disque à came K 2 Disco a camme completo K2 1
40 1835.021.359 Kurvenscheibe K 3 Cam K 3 Disque à came K 3 Disco a camme completo K3 1
41 1835.021.360 Kurvenscheibe K 4 Cam K 4 Disque à came K 4 Disco a camme completo K4 1
42
43 1835.021.361 Ringsegment Ring segment Segment d’un commutateur Segmento ad anello 1
44 1835.021.018 Bundbüchse Bushing Douille Bussola d’unione 1
45 1835.021.023 Zylinder-Büchse Cylindric bushing Douille cylindrique Bussola cilindrica 1
46 1835.021.362 Schaltnocken Tip cam Came porte-butée Camma 1
47 1835.021.066 Bundbüchse Bushing Douille Bussola d’unione 1
48
49 1911.506.458 Sechskant-Schraube Hex. screw Vis à six pans Vite esagonale 1
50 1911.705.128 Senkschraube Counter sunk screw Vis noyée Vite a testa svasata 1
51
52 1911.005.088 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 3
53 1911.005.068 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 1
54 1919.605.062 Sicherungsscheibe Lock washer Rondelle de sécurité Anello di sicurezza 1
55 1912.006.208 Sechskant-Schraube Hex screw Vis à six pans Vite esagonale 4
56 1911.004.088 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 1
57
58 1821.020.033 Flanschbüchse Bushing Douille Bussola 4
59 1821.170.004 Rippenscheibe Washer Rondelle Rondella zigrinata 1
60 1923.204.160 Federkeil Key Coin Cuneo 1
61 1910.405.062 Gewindestift Set screw Goujon leté Grano lettato 1
62 1821.012.006 Drehfeder Torsion spring Ressort de torsion Molla a torsione 1
63
* 64 1821.171.001 Poly V Keilrippenband Belt Courroie Cinghia a V 1
65
66 1821.140.037 Einphasen-Motor 230-240 V Electric motor 230-240 V Moteur électrique 230-240 V Motore elettrico monofase 230-240V 1
66
67
68 1820.090.189 Hinweisschild Indication tag Plaquette indicateur Placchetta 1
69 1923.205.640 Federkeil Key Clavette Cueno 1
70 1821.025.009 Mutter Nut Ecrou Dado 1
71 1821.020.106 Distanzring (7 x 1 mm) Spacer Anneau d'écartement Anello distanziatrice 1
72 1821.020.107 Distanzring (10,9 x 1 mm) Spacer Anneau d'écartement Anello distanziatrice 2
73 1821.020.108 Distanzring (19,75 x 2 mm) Spacer Anneau d'écartement Anello distanziatrice 2
Fig. A
* Empfohlene Ersatzteile * Recommended spare parts * Pièces de rechange recom. * Parti di ricambio raccom.
