Strapex SMA 20
60
Pos. Artikel-Nr. Benennung Part name Article Articolo Stück
Part no Quantity
No d'article
Pièce
Art. no Pezzi
36 1920.103.062 Sicherungsscheibe Retaining ring Circlips Anello di ritenuta 2
37 1916.004.088 Mutter Nut Ecrou Dado 6
38 1919.604.052 Rippenscheibe Lock washer Rondelle de sécurité Rondella zigrinata 1
39
40 1835.021.005 Klemmer, rechts Clamp, right Pince, droite Morsetto destro 1
41 1835.021.007 Klemmer, Mitte Clamp, center Pince, centre Morsetto destro centrale 1
42 1835.021.006 Klemmer, links Clamp, left Pince, gauche Morsetto sinistro 1
43 1835.021.009 Stössel Stem Coulisseau Asta 2
44 1835.021.010 Stössel, Mitte Stem, center Coulisseau, centre Asta centrale 1
45 1835.021.011 Druckstück Pressure piece Pièce de pression Elemento di pressione 1
46 1821.010.015 Druckfeder Compression spring Ressort de pression Molla a pressione 1
47
48 1911.306.162 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 6
49 1911.606.408 Sechskant-Schraube Hex. screw Vis à six pans Vite esagonale 2
50 1911.606.728 Sechskant-Schraube Hex. screw Vis à six pans Vite esagonale 1
51 1835.021.059 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 1
52 1911.008.548 Zylinderschraube Cylinder screw Vis cylindrique Vite cilindrica 1
53
54
55
56 1835.021.051 Bride Flange Bride Brida 1
57 1835.021.060 Federhülse Spring bushing Douille à ressort Bussola a pressione 3
58 1835.021.058 Schwenkbolzen Swivel bolt Goujon pivotant Perno orientabile 1
59 1821.031.012 Bolzen Bolt Goujon Perno 1
60 1821.010.016 Druckfeder Compression spring Ressort à pression Molla a pressione 3
61 2255.100.476 Distanzbüchse Spacer bushing Douille d’écartement Bussola distanziatrice 2
62
63
64 1835.021.365 Support Support Support Supporto 1
65 1835.021.366 Bolzen Bolt Goujon Perno 1
* 66 1821.012.005 Drehfeder Torsion spring Ressort de torsion Molla a torsione 1
67
68
69
* Empfohlene Ersatzteile * Recommended spare parts * Pièces de rechange recom. * Parti di ricambio raccom. * Piezas de recambio recom.
Fig. B
