Objet350 User Guide 6 Operating and Maintaining the Objet350 3DPrinter
DOC-17001 Rev.G 6-35
4. Loosenthetwoscrewssecuringthesuctiontubeontheprintblock.
Figure6-37Liftingthesuctiontube
5. Liftthesuctiontubetosecureitinaraisedposition.
6. Removethetwoscrewssecuringthecoveringoftherollerwastecollector
andremoveit.
Beverycarefultosavethecoveringscrews.Thesearespecialscrews;if
theyarelost,youneedtoorderreplacements.
Figure6-38Removingtherollerwastecollectorcovering
7. Removethecoveringbypullingitout,andthenlowerit.
