Stratasys Objet350 - Objet Studio Software

Objet350 User Guide 3 Introducing the Objet350 3D Printing System
DOC-17001 Rev.G 3-9
Objet Studio Software
TheObjetStudioprogramfortheObjet3503Dprintingsystemconsistsof
twomainscreens:
•TraySettings/ModelSettings
•JobManager
TraySettings/ModelSettings
IntheTray SettingsandModel Settingsscreens,youpreparesourcefilesfor
productioninObjet3503Dprinters.ObjetStudiooffersyouawidevarietyof
file-preparationoptions,butalwaysconsistsofthefollowingbasicprocedure:
1. Placingoneormoreobjectsonthebuild tray
2. Positioningtheobject(s)onthetray
3. Configuringobjectandtrayparameters
4. Savingthetrayconfigurationasanobjtf(trayformat)file
5. SendingtheobjtffiletotheObjet3503Dprinterforproduction
UsingObjetStudiotoperformthesetasksisdescribedindetailinChapter5,
"UsingObjetStudio".
JobManager
TheJob Managerscreenisdifferentforclientworkstationsandforthe
computerconnecteddirectlytotheObjet3503Dprinter.
•InObjetStudioinstalledonthedirectly-connectedcomputer(server),the
Job Managerscreendisplaysthequeueandstatusforalljobssenttothe
3Dprinterbytheserveritselfandbyallclientcomputersonthenetwork.
Alljobsdisplayedcanbeeditedandmanipulated.
•InObjetStudioinstalledonclientcomputers,theJobManagerscreen
displaysthequeueandstatusonlyforjobssenttoa3Dprinterserverfrom
thatcomputer.Onlythesejobscanbeeditedandmanipulatedfromthe
clientcomputer.
Clientcomputerscanbeconnected,viathelocalnetwork,toPolyJet3D
printers,butonlytooneatatime.TheJob Managerscreendisplaysthe
statusofthe3Dprintertowhichtheclientiscurrentlyconnected.
