Objet350 User Guide 5 Using Objet Studio
DOC-17001 Rev.G 5-32
Automatic
Positioning
Afterplacingseveralobjectsonthebuildtray,youcanletObjetStudio
arrangethembeforeprinting.Thisensuresthattheobjectsarepositioned
properly,andthattheywillbeprintedintheshortesttimeandwitha
minimumofmaterial.
Toautomaticallyarrangeobjectsonthebuildtray:
➢ OntheTray Settingsribbon,click .
or—
FromtheToolsmenu,selectAutomaticPlacement.
Theeffectsofautomaticpositioningareshowninthefiguresbelow.
Figure5-36Traybeforeobjectsareproperlyarranged
Figure5-37TrayarrangementafterapplyingAutomaticPlacement
