Commissioning
142
Verti-Mix SF / Verti-Mix Double SF Version 06.12
6.6.7 Steering
The standard machine model is equipped with a front axle steering.
Hydraulic steering reduces the effort required to actuate the steering
wheel.
Four-wheel steering is an optional extra. Four-wheel steering with
opposite steering angle of the front and rear wheels acts as a
reduction of the wheelbase and the turning radius. Four-wheel
steering allows to manoeuvre the machine under difficult or strongly
limited spacious conditions.
Hydraulic steering only works with the diesel engine running.
Four-wheel steering can be switched on and off as required.
With the four-wheel steering switched on, the travelling speed is
limited to 16 km/h.
First align the wheels in a straight line before switching the four-wheel
steering on or off.
WARNING
Impairment of driving safety if the steering wheel is difficult to
turn due to a defect in the hydraulic steering or due to the
hydraulic steering not working!
Have a defective steering immediately repaired.
6.6.7.1 Switch four-wheel steering on
1. Press the toggle switch "Four-wheel
steering".
The four-wheel steering is switched on and
the symbol "Four-wheel steering"
appears in the terminal.
2. Align the wheels of the front axle in a
straight line by means of a short forward or
reverse travel of the machine.
Fig. 95
6.6.7.2 Switch four-wheel steering off
1. Press the toggle switch "Four-wheel
steering".
The four-wheel steering is switched off and
the symbol "Front axle steering"
appears in the terminal.
2. Align the wheels of the rear axle in a
straight line by means of a short forward or
reverse travel of the machine.
Fig. 96
